Products Name：Square 2x2 T-BAR Louver Lighting
Product Number：NM408-R3751
Light Source：LED
Wattage：In Description
Description：
Product No. : NM408-R3751
Housing :
Frame- 1.0t integrally formed iron plate with high-quality white powder coated.
Louver- PC louver, featuring fire-resistant and flame retardant (V-0 grade)
Dimension : 108 x 1158 x 103 mm
Input Voltage : AC 110V / 220V
Power Consumption : 26W / 32W
Luminous Efficacy : 103 lm / 100 lm (+-3%)
Luminous Flux : 2670 lm / 3200 lm (+-3%)
UGR : Lateral 14.0 ; longitudinal 13.9
Power Factor : ≥0.9
Color Temperature : 3000K, 4000K, 5000K
CRI : >80
Luminance Decrease : 50000hrs before luminous flux is reduced to 80%
Installation Method : Recessed
Operation Temperature : Celsius 0°C ~ 40°C
T-BAR Large Span : Type 1
˙Area: 19.4m X 19.4m, adopting power consumption 26W, luminous flux 2670 lm, total 88 sets of lightings for calculation :
Wide span for lighting : horizonal 1.8m ; vertical 2.4m
Total Power Consumption : 26 (power consumption/set) x 88 sets = 2288W
Area : 19.4m x 19.4m = 376.4 m2
Power Consumption per square meter : 6.08 W/m2
Average Lux : 610.92 lux
Taiwan Certification:
BSMI CNS certification: CI3A006979005102
